Internal Combustion: Cushion

Toyota Box Car Special (8,000-12,000 LBS)

Fuel Type:	Gas / LPG Fuel Type
Length to Forkface:	95.5 -106.3 in
Load Capacity:	8,000 - 12,000 lb. Load Capacity
Overall Width:	50 - 55.9 in

HANGCHA Box Car Special Forklift (8,000-12,000 LBS)

ENVIRONMENTALLY EFFICIENT | North American EPA Certified Engine - The PSI 4.3L LPG engine is in compliance with North American EPA Standards. Although it meets these standards, the engine still has the power and torque to get the job done. This engine is also electronically controlled to increase the fuel economy and the reliability of the trucks. LED Light System - LED lights are used throughout the entire truck. The lights are energy-efficient, have a longer service life, and offer a significant increase in performance. Environmentally-Friendly Materials - Environmentally-friendly materials are also used throughout the truck to minimize environmental damage and impact.

COMFORT | Ergonomic Design - The small diameter, adjustable steering wheel, electro-hydraulic steering, and the combination switch increase the ease of operation and operator comfort substantially. Wide View Mast - The mast has been redesigned to include new types of steel channels and a new mast system. This was done to increase forward visibility for the operator. Large LCD Instrument Panel - The newly developed LCD instrument display has additional functions and offers more stable performance. Important information including the running status of the entire truck and a check engine light can be displayed. This allows the operator to easily understand the status of the truck for easy maintenance. Panoramic Rearview Mirror - The panoramic rearview mirror allows the operator to have wider rear visibility when operating the forklift. Large Handgrip - The large handgrip on the overhead guard is designed to allow the operator to get in and out of the truck safer and easier.

RELIABILITY | OKAMURA Transmission - The world-renown OKAMURA transmission, with the Power Take-Off (PTO) feature, is used in our Box Car Special forklift. This transmission was chosen as apart of our forklift’s design for its reliability. The gear pump is also extremely efficient. New Integrated Fuse Box - The next generation of integrated fuse box has been added to the truck. It offers a better layout, ease of service and maintenance, and is waterproof. The entire truck is equipped with waterproof connectors to increase the electronics’ reliability. Reliable Hydraulic System - The hydraulic system has a longer service life and an increase in efficiency thanks to the optimized hydraulic breather structure with a built-in return oil filter and the load-sensing hydraulic steering system. Optimized Cooling System - The cooling system has been designed to maximize cooling and increase the reliability of the engine when working under heavy loads. This system uses an aluminum radiator, an independent oil cooler, an optimized heat transfer channel, and a dual-hole counterweight to increase cooling efficiency. Steering Axle - The steering axle uses large conical bearings on the master pin, buffer blocks, and a large-diameter steering cylinder to substantially increase the reliability and service life of the steering system.

SAFETY | High-Strength Overhead Guard - The overhead guard is fabricated with specially shaped steel tubes to increase its structural rigidity and strength. It is also designed to be easily disassembled and reassembled for repairs. The guard features a flexible connection between it and the chassis to decrease vibrations. All of these features are responsible for increased operator safety and comfort. Maintenance Hatch with a Safety Latch - The maintenance hatch opens wide enough to provide easy serviceability of key components. The safety latch prevents the hatch from compromising operator safety when using the truck.

Toyota Core IC Cushion (3,000-6,500 LBS)

Fuel Type:	Gas / LPG / Dual Fuel Fuel Type
Length to forkface:	82.3 - 98.6 in
Load Capacity:	3,000 - 6,500 lb. Load Capacity
Overall Width:	37.2 - 43.7 in

Doosan IC Cushion (3,000-12,000 LBS)

HANGCHA IC Cushion Forklift (3,000-6,500 LBS)

SAFETY | High-Strength Overhead Guard - The overhead guard is fabricated with specially shaped steel tubes to increase its structural rigidity and strength. It is also designed to be easily disassembled and reassembled for repairs. The guard features a flexible connection between it and the chassis to decrease vibrations. All of these features are responsible for increased operator safety and comfort. Maintenance Hatch with a Saftey Latch - The maintenance hatch opens wide enough to provide easy serviceability of key components. The safety latch prevents the hatch from compromising operator safety when using the truck.

RELIABILITY | New Integrated Fuse Box - The next generation of integrated fuse box has been added to the truck. It offers a better layout, ease of service and maintenance, and is waterproof. The entire truck is equipped with waterproof connectors to increase the electronics’ reliability. Reliable Hydraulic System - The hydraulic system has a longer service life and an increase in efficiency thanks to the optimized hydraulic breather structure with a built-in return oil filter and the load-sensing hydraulic steering system. Optimized Cooling System - The cooling system has been designed to maximize cooling and increase the reliability of the engine when working under heavy loads. This system uses an aluminum radiator, an independent oil cooler, an optimized heat transfer channel, and a dual-hole counterweight to increase cooling efficiency. Steering Axle - The steering axle uses large conical bearings on the master pin, buffer blocks, and a large-diameter steering cylinder to substantially increase the reliability and service life of the steering system. Tilt-Back LP Bracket (Option for the 3,000-3,500lb truck) - The tilt-back cylinder holder makes replacing the LPG cylinder and opening the maintenance hatch for service easy.

ENVIRONMENTALLY EFFICIENT | North American EPA Certified Engines - The GCT GK21/25 engines are in compliance with North American EPA emissions standards. Although they meet these standards, they still have the power and torque to get the job done. These engines are also electronically controlled to increase the fuel economy and the reliability of the trucks. LED Light System - LED lights are used throughout the entire truck. The lights are energy-efficient, have a longer service life, and offer a significant increase in performance. Environmentally Friendly Materials - Environmentally friendly materials are also used throughout the truck to minimize environmental damage and impact.

COMFORT | Ergonomic Design - The small diameter, adjustable steering wheel, electro-hydraulic steering, and the combination switch increase the ease of operation and operator comfort substantially. Wide View Mast - The mast has been redesigned to include new types of steel channels and a new mast system. This was done to increase forward visibility for the operator. Large LCD Instrument Panel - The newly developed LCD instrument display has additional functions and offers more stable performance. Important information including the running status of the entire truck and a check engine light can be displayed. This allows the operator to easily understand the status of the truck for easy maintenance. The instrument display is made up of a 4″ color LCD screen with four interactive buttons and one CAN bus communication function. The communication protocol is compatible with CANopen and SAE J1939 standards. Panoramic Rearview Mirror - The panoramic rearview mirror allows the operator to have wider rear visibility when operating the forklift. Large Handgrip - The large handgrip on the overhead guard is designed to allow the operator to get in and out of the truck safer and easier.

HANGCHA IC Cushion Tire Forklift (13,500-15,500 LBS)

RELIABILITY | OKAMURA Transmission - The world-renown OKAMURA transmission, with the Power Take-Off (PTO) feature, is used in our Box Car Special forklift. This transmission was chosen as apart of our forklift’s design for its reliability. The gear pump is also extremely efficient. New Integrated Fuse Box - The next generation of integrated fuse box has been added to the truck. It offers a better layout, ease of service and maintenance, and is waterproof. The entire truck is equipped with waterproof connectors to increase the electronics’ reliability. Reliable Hydraulic System - The truck adopts a high-pressure hydraulic system and steering load sensing technology, which can effectively improve operational efficiency. The multi-way valve uses the double pump confluence, the single pump discharge system, reduces gives off heat, the standard matches the hydraulic pressure oil to dissipate heat, enhances the hydraulic pressure system reliability. Optimized Cooling System - The cooling system has been designed to maximize cooling and increase the reliability of the engine when working under heavy loads. This system uses an aluminum radiator, an independent oil cooler, an optimized heat transfer channel, and a dual-hole counterweight to increase cooling efficiency. Steering Axle - The steering axle uses large conical bearings on the master pin, buffer blocks, and a large-diameter steering cylinder to substantially increase the reliability and service life of the steering system.

SAFETY | High-Strength Overhead Guard - The overhead guard is fabricated with specially shaped steel tubes to increase its structural rigidity and strength. It is also designed to be easily disassembled and reassembled for repairs. The guard features a flexible connection between it and the chassis to decrease vibrations. Maintenance Hatch with a Safety Latch - The maintenance hatch opens wide enough to provide easy serviceability of key components. The safety latch prevents the hatch from compromising operator safety when using the truck.

Toyota Large IC Cushion (8,000-15,500 LBS)

Fuel Type:	Gas / LPG Fuel Type
Length to forkface:	103 - 118.1 in
Load Capacity:	8,000 - 15,500 lb. Load Capacity
Overall Width:	50 - 57.1 in

HANGCHA Paper Roll Special (12,000 LBS)

COMFORT | Ergonomic Design - The small diameter, adjustable steering wheel, electro-hydraulic steering, and the combination switch increase the ease of operation and operator comfort substantially. The hydraulic levers are positioned to allow for easy operation. Wide View Mast - The mast has been redesigned to include new types of steel channels and a new mast system. This was done to increase forward visibility for the operator. Large LCD Instrument Panel - The new LCD instrument display has additional functions and offers more stable performance. Important information including the running status of the entire truck and a check engine light can be displayed. This allows the operator to easily understand the status of the truck for easy maintenance. Next to the LCD panel is a low LPG fuel warning indicator. Panoramic Rearview Mirror - The panoramic rearview mirror allows the operator to have wider rear visibility when operating the forklift. Large Handgrip - The large handgrip on the overhead guard is designed to allow the operator to get in and out of the truck safer and easier.
